A lightweight perimeter frame offers optimised rigidity for stability at speed while the short wheelbase facilitates agile handling. High ground clearance allows riders to more easily clear technical terrain features, resulting in confident trail riding.
Serious off-road fun starts with the fuel-injected 292 cc liquid-cooled four-stroke Single, delivering crisp response, quick-revving power and strong low-end torque. The KLX300R is built tough with an engine designed to withstand the rigours of hard trail riding.
Full-size wheels and powerful disc brakes make the KLX300R ready for tough off-road terrain.
The KLX300R is built for serious play and is equipped with long-travel suspension to confidently handle the rigors of aggressive off-road riding.
| Engine type | Liquid-cooled, 4-stroke, single-cylinder |
|---|---|
| Valve system | DOHC, 4 valves |
| Bore x stroke | 78.0 x 61.2 mm |
| Displacement | 292 cm³ |
| Fuel system | Fuel injection: 34 mm x 1 |
| Lubrication | Forced lubrication, wet sump |
| Starting system | Electric |
| Ignition system | Digital |
| Transmission | 6-speed, return shift |
|---|---|
| Clutch | Wet, multi disc |
| Primary reduction ratio | 2.800 (84/30) |
| Gear ratios 1st | 3.000 (30/10) |
| Gear ratios 2nd | 2.000 (30/15) |
| Gear ratios 3rd | 1.500 (27/18) |
| Gear ratios 4th | 1.250 (25/20) |
| Gear ratios 5th | 1.050 (21/20) |
| Gear ratios 6th | 0.952 (20/21) |
| Final drive | Chain |
| Final reduction ratio | 3.571 (50/14) |
| Frame type | Perimeter, high-tensile steel |
|---|---|
| Trail | 109 mm |
| Wheel travel front | 285 mm |
| Wheel travel rear | 285 mm |
| Tyre, front | 80/100-21 51M |
| L x W x H | 2,120 x 825 x 1,245 mm |
| Steering angle L/R | 45° / 45° |
| Wheel base | 1,435 mm |
| Ground clearance | 300 mm |
| Fuel capacity | 7.9 litres |
| Seat height | 900 mm |
| Curb mass | 128 kg |
| Front brake type | Single semi-floating petal disc |
|---|---|
| Front brake diameter | Ø 270 mm |
| Front brake caliper type | Dual-piston |
| Rear brake type | Single petal disc |
| Rear brake diameter | Ø 240 mm |
| Rear brake caliper type | Single-piston |
| Front suspension diameter | Ø 43 mm |
