MULE PRO-MX side x sides will answer the task with grit and muscle, all backed by the industry-leading Kawasaki STRONG 3-Year Limited Warranty.
Drive comfortably in a roomy cabin that offers generous leg, shoulder, and head clearance, along with refined ergonomics.
MULE PRO-MX side x sides come standard with convenience features that allow you to work easier and accomplish more in less time.
Optimised mid-size chassis offers sure-footed and agile handling performance along with rugged capability.
Power through your workday with the 695 cc fuel-injected engine of the MULE PRO-MX side x side. Relish the challenge of rugged and hilly terrain with class-leading torque and responsive power.
| Engine type | Liquid-cooled, 4-stroke, single-cylinder |
|---|---|
| Compression ratio | 10.3:1 |
| Valve system | SOHC, 4 valves |
| Bore x stroke | 102.0 x 85.0 mm |
| Displacement | 695 cm³ |
| Fuel system | Fuel injection: 44 mm x 1 |
| Lubrication | Forced lubrication, wet sump |
| Starting system | Electric |
| Ignition system | Battery & Coil (transistorised ignition) |
| Maximum power | 33.0 kW {45 PS} / 6,000 rpm |
|---|---|
| Maximum torque | 58.0 N•m {5.9 kgf•m} / 5,000 rpm |
| Transmission | CVT, centrifugal clutch |
| Primary reduction ratio | 0.791 ~ 2.451 |
| Final drive | Shaft 2WD/4WD, dual-mode differential |
| Final reduction ratio | 4.375 (35/8) |
| Frame type | Ladder type, tubular steel |
|---|---|
| Wheel travel front | 218 mm |
| Wheel travel rear | 232 mm |
| Tyre, front | 25 x 8.00 R12 |
| Tyre, rear | 25 x 10.00 R12 |
| L x W x H | 2,840 x 1,525 x 1,925 mm |
| Wheel base | 2,005 mm |
| Ground clearance | 270 mm |
| Fuel capacity | 36.0 litres |
| Seat height | 850 mm |
| Curb mass | 737 kg |
| Parking brake | Dual discs (mechanical) |
|---|---|
| Front brake type | Dual discs |
| Front brake diameter | Ø 212 mm |
| Front brake caliper type | Dual-piston |
| Rear brake type | Dual discs |
| Rear brake diameter | Ø 212 mm |
| Rear brake caliper type | Single-piston |
| Front suspension type | Double wishbone |
| Rear suspension type | Double wishbone |
